Cinghie di trasmissione

Chiorino manufactures a wide range of high-duty power transmission belts, whose versatility and energy-saving properties make them a key component in high demanding power transmission industries, such as packaging, paper and printing, textile and raw materials. They can be supplied endless spliced or open-end, combining different raw materials, and customized configuration.
Chiorino’s offer includes certified food compliant power transmission belts.

Chiorino’s power transmission belts are manufactured with top-quality materials and guarantee great versatility and sustainable performance.

Chiorino’s machine tapes offer an extensive variety of textures, whose properties allow to reach outstanding performance in many belting applications.

The continuous research and development on raw materials, chemical combinations and state-of-the-art technologies, allows Chiorino to manufacture fast-joint machine tapes reaching a significant diversification in products and applications.

Main features:

• High longitudinal flexibility
• Uniform coefficient of friction
• Superior wear resistance
• Suitable for high speed machines
• Antistatic and non-conductive
• Energy savings

Chiorino’s conveyor and process belts are certified to offer total safety and risk minimization, in compliance with the strictest European and international regulations, safeguarding customers’ operations as well as consumers’ health.

aggiungi valore al tuo processo

Elastomeri rigeneranti di alta gamma

scopri

Elastomeri a prestazioni elevate

scopri

Elevata precisione nella stampa di tessuti

scopri

Categoria

Codice	Materiale	Spessore [mm]	Allungamento 1% [N/mm]	Tipo
CG256	Elastomero sintetico	3.00	60.0	T60/30A
CG325	Elastomero sintetico	2.00	15.0	T25/20E
CG331	Elastomero sintetico	2.50	15.0	T25/25E
CG329	Elastomero sintetico	2.50	19.0	T40/25E
CG317	Elastomero carbossilico (XNBR)	2.60	19.0	T40/26E-OE
CG332	Elastomero sintetico	3.00	19.0	T40/30E
CG328	Elastomero sintetico	3.00	21.0	T55/30E
CG334	Elastomero sintetico	1.40	2.0	T0 HS
CG335	Elastomero sintetico	1.50	5.0	T1 HS
CG341	Elastomero sintetico	2.10	5.0	T1R HS
CG336	Elastomero sintetico	2.35	8.0	T2 HS
CG337	Elastomero sintetico	2.60	11.0	T3 HS
CG342	Elastomero sintetico	3.00	8.0	T2R HS
CG338	Elastomero sintetico	3.10	12.5	T4 HS
CG345	Elastomero sintetico	3.10	15.0	T4-15 HS
CG343	Elastomero sintetico	3.20	11.0	T3R HS
CG339	Elastomero sintetico	3.50	18.0	T6 HS
CG344	Elastomero sintetico	3.90	12.5	T4R HS
CG3	Tessuto impregnato di poliuretano (TPU)	0.90	2.0	P0
CG1	Tessuto impregnato di poliuretano (TPU)	1.00	3.0	PR0
CG217	Tessuto impregnato di poliuretano (TPU)	1.40	5.0	P1
CG219	Tessuto impregnato di poliuretano (TPU)	2.10	7.5	P2
CG12	Poliuretano (TPU)	4.90	30.0	Z9
CG13	Poliuretano (TPU)	5.60	40.0	Z12
CG296	Elastomero sintetico	3.00	15.0	DG-E 10/30 HS
CG297	Elastomero sintetico	4.00	15.0	DG-E 10/40 HS
CG298	Elastomero sintetico	5.00	15.0	DG-E 10/50 HS
CG299	Elastomero sintetico	6.00	15.0	DG-E 10/60 HS
CG289	Elastomero sintetico	1.60	5.0	DG1/15 HS
CG292	Elastomero sintetico	2.40	8.0	DG2/20 HS
CG290	Elastomero sintetico	3.00	5.0	DG1/30 HS
CG327	Elastomero sintetico	3.00	5.0	DG1/30 HS Food Grade
CG293	Elastomero sintetico	3.20	8.0	DG2/30 HS
CG291	Elastomero sintetico	4.00	5.0	DG1/40 HS
CG326	Elastomero sintetico	4.00	5.0	DG1/40 HS Food Grade
CG294	Elastomero sintetico	4.00	8.0	DG2/40 HS
CG295	Elastomero sintetico	5.50	8.0	DG2/60 HS
CG67	Cuoio	3.20	2.0	LL0 L
CG34	Cuoio	3.20	5.0	LL1
CG35	Cuoio	4.00	7.5	LL2
CG36	Cuoio	4.20	10.0	LL3
CG37	Cuoio	4.80	15.0	LL4
CG38	Cuoio	6.00	20.0	LL6
CG39	Cuoio	7.20	30.0	LL9
CG24	Poliuretano (TPU)	2.40	3.0	LT0R
CG25	Poliuretano (TPU)	2.50	5.0	LT1
CG26	Poliuretano (TPU)	3.10	7.5	LT2
CG27	Poliuretano (TPU)	3.30	10.0	LT3
CG28	Poliuretano (TPU)	3.80	15.0	LT4
CG29	Poliuretano (TPU)	4.40	20.0	LT6
CG30	Poliuretano (TPU)	5.60	30.0	LT9
CG31	Poliuretano (TPU)	6.10	40.0	LT12

Dati derivanti condizioni ambientali standard. Eventuali modifiche possono essere apportate senza preavviso.

Codice	Tipo	Dichiarazioni di conformità
CG256	T60/30A	REACH
CG325	T25/20E	REACH
CG331	T25/25E	REACH
CG329	T40/25E	REACH
CG317	T40/26E-OE	REACH
CG332	T40/30E	REACH
CG328	T55/30E	REACH
CG334	T0 HS	REACH
CG335	T1 HS	REACH
CG341	T1R HS	REACH
CG336	T2 HS	REACH
CG337	T3 HS	REACH
CG342	T2R HS	REACH
CG338	T4 HS	REACH
CG345	T4-15 HS	REACH
CG343	T3R HS	REACH
CG339	T6 HS	REACH
CG344	T4R HS	REACH
CG3	P0	REACH
CG1	PR0	REACH
CG217	P1	REACH
CG219	P2	REACH
CG12	Z9	REACH
CG13	Z12	REACH
CG296	DG-E 10/30 HS	REACH
CG297	DG-E 10/40 HS	REACH
CG298	DG-E 10/50 HS	REACH
CG299	DG-E 10/60 HS	REACH
CG289	DG1/15 HS	REACH
CG292	DG2/20 HS	REACH
CG290	DG1/30 HS	REACH
CG327	DG1/30 HS Food Grade	REACH	EU 1935
CG293	DG2/30 HS	REACH
CG291	DG1/40 HS	REACH
CG326	DG1/40 HS Food Grade	REACH	EU 1935
CG294	DG2/40 HS	REACH
CG295	DG2/60 HS	REACH
CG67	LL0 L
CG34	LL1	REACH
CG35	LL2	REACH
CG36	LL3	REACH
CG37	LL4	REACH
CG38	LL6	REACH
CG39	LL9	REACH
CG24	LT0R	REACH
CG25	LT1	REACH
CG26	LT2	REACH
CG27	LT3	REACH
CG28	LT4	REACH
CG29	LT6	REACH
CG30	LT9	REACH
CG31	LT12	REACH
