Nastri omogenei e dentati

Nastri omogenei e dentati

Chiorino’s homogeneous & drive belts are developed to use the positive drive to overcome the most common mechanical problems of conventional flat belts, which are slippage and off-tracking. The reinforced traction core and toothed profiles on the running side are engineered to provide different drive effects, thus meeting different application requirements and uses.
Chiorino’s homogeneous & drive belts are ideal for conveying and processing products in the food and agricultural industry and can be supplied with central or full width lugs, with different pitches, reinforced or no reinforced.

Chiorino’s homogeneous & drive belts can be fabricated in different materials to provide a great mechanical performance safeguarding food safety.

Chiorino’s homogeneous & drive belts offer an extensive variety of textures, resistant to cuts and abrasions and easy to clean and sanitize.

PN

GB

RG

The continuous research and development on raw materials, chemical combinations and state-of-the-art technologies, allows Chiorino to manufacture a great variety of homogeneous & drive belts and related accessories, thus reaching a significant diversification in products and applications.

Main features:
• Antimicrobial HP® Product System
• Excellent mechanical stability
• Food grade
• Easy to install, splice and maintain
• Up to 2000 mm width
• Ideal for Z or “swan neck” conveyors

Chiorino’s homogeneous & drive belts are certified to offer total safety and risk minimization, in compliance with the strictest European and international regulations, safeguarding customers’ operations as well as consumers’ health.

confezionamento e personalizzazione

Chiorino Marking Technology™

Accessories

aggiungi valore al tuo processo
Nastri omogenei e dentati antimicrobici
scopri
Nastri omogenei e dentati antimicrobici per piccoli diametri
scopri
Nastri monolitici
scopri
la nostra selezione di prodotti
Tipo Categoria Spessore [mm] Allungamento 1% [N/mm] Codice Scheda tecnica
HP Compact 15 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 1.50 5.00 NA1724A
HP Compact Minidrive 15/20 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 1.50 5.00 NA1724F_D6
HP Compact Minidrive 15/20 PN blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 1.85 5.00 NA1761F_D6
HP Compact 20 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.00 8.00 NA1729A
HP Compact Drive 20/40 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.00 8.00 NA1729C_D13
HP Compact 25 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.50 8.00 NA1706A
HP Compact 25 PN blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.50 8.00 NA1730A
HP Compact 25 RG blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.50 8.00 NA1725A
HP Compact 25 VL blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.50 8.00 NA1726A
HP Compact Drive 25/40 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.50 8.00 NA1706C_D13
HP Compact Drive 25/40 PN blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.50 8.00 NA1730C_D13
HP Compact Drive 25/40 RG blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.50 8.00 NA1725C_D13
HP Compact Drive 25/40 VL blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.50 8.00 NA1726C_D13
HP Compact RG 25 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 2.50 8.00 NA1725A_RG
HP Compact 40 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 4.00 15.00 NA1727A
HP Compact Drive 40/40 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI 4.00 15.00 NA1727C_D13
Compact Minidrive 15/20 blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI 1.50 5.00 NA1461F_D6
Compact 25 blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI 2.50 8.00 NA1460A
Compact 25 PN blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI 2.50 8.00 NA1561A
Compact Drive 25/40 blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI 2.50 8.00 NA1460C_D13
Compact Drive 25/40 PN blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI 2.50 8.00 NA1561C_D13
Compact Minidrive 15/20 A blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI 1.50 10.00 NA1482F_D6
ProDrive C-S 30/40 GS LB PRODRIVE NASTRI MONOLITICI 3.00 4.00 NA1822
ProDrive C-S 30/40 GS W PRODRIVE NASTRI MONOLITICI 3.00 4.00 NA1824
ProDrive C-S 30/40 LB PRODRIVE NASTRI MONOLITICI 3.00 4.00 NA2595
ProDrive F-S 28/25 GS LB PRODRIVE NASTRI MONOLITICI 2.80 4.00 NA1776
ProDrive F-S 30/50 GB LB PRODRIVE NASTRI MONOLITICI 3.00 4.00 NA1773
ProDrive F-S 30/50 GS LB PRODRIVE NASTRI MONOLITICI 3.00 4.00 NA1810
ProDrive F-S 30/50 LB PRODRIVE NASTRI MONOLITICI 3.00 4.00 NA1774
ProDrive S 30 LB PRODRIVE NASTRI MONOLITICI 3.00 4.00 NA1823

Dati derivanti condizioni ambientali standard. Eventuali modifiche possono essere apportate senza preavviso.

Tipo Categoria Codice Dichiarazioni di conformità
HP Compact 15 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1724A REACH EU 1935 FDA
HP Compact Minidrive 15/20 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1724F_D6 REACH EU 1935 FDA
HP Compact Minidrive 15/20 PN blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1761F_D6 REACH EU 1935 FDA
HP Compact 20 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1729A REACH EU 1935 FDA
HP Compact Drive 20/40 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1729C_D13 REACH EU 1935 FDA
HP Compact 25 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1706A REACH EU 1935 FDA VEGAN
HP Compact 25 PN blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1730A REACH EU 1935 FDA
HP Compact 25 RG blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1725A REACH EU 1935 FDA
HP Compact 25 VL blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1726A REACH EU 1935 FDA
HP Compact Drive 25/40 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1706C_D13 REACH EU 1935 FDA
HP Compact Drive 25/40 PN blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1730C_D13 REACH EU 1935 FDA
HP Compact Drive 25/40 RG blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1725C_D13 REACH EU 1935 FDA
HP Compact Drive 25/40 VL blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1726C_D13 REACH EU 1935 FDA
HP Compact RG 25 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1725A_RG REACH EU 1935 FDA
HP Compact 40 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1727A REACH EU 1935 FDA
HP Compact Drive 40/40 blue AM POLIURETANO HP AM COMPACT - OMOGENEI e DENTATI NA1727C_D13 REACH EU 1935 FDA
Compact Minidrive 15/20 blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI NA1461F_D6 REACH EU 1935 FDA NSF
Compact 25 blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI NA1460A REACH EU 1935 FDA NSF
Compact 25 PN blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI NA1561A REACH EU 1935 FDA
Compact Drive 25/40 blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI NA1460C_D13 REACH EU 1935 FDA NSF
Compact Drive 25/40 PN blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI NA1561C_D13 REACH EU 1935 FDA
Compact Minidrive 15/20 A blue DET DET COMPACT DRIVE - OMOGENEI e DENTATI NA1482F_D6 REACH EU 1935 FDA NSF
ProDrive C-S 30/40 GS LB PRODRIVE NASTRI MONOLITICI NA1822 REACH EU 1935 FDA
ProDrive C-S 30/40 GS W PRODRIVE NASTRI MONOLITICI NA1824 REACH EU 1935 FDA
ProDrive C-S 30/40 LB PRODRIVE NASTRI MONOLITICI NA2595 REACH EU 1935 FDA
ProDrive F-S 28/25 GS LB PRODRIVE NASTRI MONOLITICI NA1776 REACH EU 1935 FDA
ProDrive F-S 30/50 GB LB PRODRIVE NASTRI MONOLITICI NA1773 REACH EU 1935 FDA
ProDrive F-S 30/50 GS LB PRODRIVE NASTRI MONOLITICI NA1810 REACH EU 1935 FDA
ProDrive F-S 30/50 LB PRODRIVE NASTRI MONOLITICI NA1774 REACH EU 1935 FDA
ProDrive S 30 LB PRODRIVE NASTRI MONOLITICI NA1823 REACH EU 1935 FDA
